SS316L Heated WFI Storage Tank (WFI Tank)
  • SS316L Heated WFI Storage Tank (WFI Tank)
  • SS316L Heated WFI Storage Tank (WFI Tank)

SS316L Heated WFI Storage Tank (WFI Tank)

The WFI storage tank is used to store water for Injection under controlled hygienic conditions in pharmaceutical water systems. Built with SS316L or SS304 stainless steel, sanitary instrumentation, vent filtration, and a polished inner surface, the tank supports clean storage, easier monitoring, and reliable integration with WFI distribution systems.

Request a Quote
Heated WFI Storage Tank

Maintaining stable temperature is essential for WFI storage and circulation. The heated WFI storage tank is designed with heating and heat preservation functions to help keep Water for Injection within the required process conditions while supporting hygienic storage and easier system operation.

The interlayer helical coil can be heated by steam or cooled by cooling water, giving manufacturers better flexibility for temperature control. Composite silicate needle felt insulation helps reduce heat loss, while the Ra0.4 mirror-polished inner surface, sanitary level sensor, temperature transmitter, cleaning device, and vent filter support clean operation, monitoring, and maintenance.

Features
  • Heating and heat preservation functions help maintain stable WFI storage conditions.
  • The interlayer helical coil can be heated by steam or cooled by cooling water, supporting flexible temperature control.
  • Composite silicate needle felt insulation helps reduce heat loss and supports more efficient energy use.
  • Temperature transmitter supports real-time temperature monitoring during storage.
  • Sanitary level sensor helps monitor liquid level for easier operation and control.
  • Cleaning device supports easier internal tank cleaning and maintenance.
  • Vent filter helps protect the stored WFI by supporting hygienic tank ventilation.
  • SS316L or SS304 can be used for the inner tank shell to match different project requirements.
  • Ra0.4 mirror-polished interior surface helps improve cleanability and reduce residue buildup.
  • Satin-polished exterior surface gives the tank a clean and professional finish.
  • The heated WFI storage tank can be customized according to your WFI storage capacity, temperature control needs, and clean utility layout. Contact our team to discuss the right tank configuration for your WFI system.
Vertical WFI Storage Tank
Model Volume (L) Dimensions (mm)
D D1 H H1 H2 H3 H4
CHL300 300 800 900 1484 460 461 820 400
CHL500 500 900 1000 1587 530 530 928 400
CHL1000 1000 1100 1200 1878 750 750 1356 400
CHL2000 2000 1300 1400 2463 1220 1220 1926 400
CHL3000 3000 1600 1700 2395 1220 1100 2070 400
CHL4000 4000 1800 1900 2557 1220 1220 2220 400
CHL5000 5000 1900 2000 2637 1220 1220 2220 400
CHL6000 6000 2000 2100 2806 1380 1380 2206 400
CHL8000 8000 2200 2300 3226 1500 1500 2680 400
CHL10000 10000 2400 2500 3450 1580 1780 2780 400
Horizontal WFI Storage Tank
Model Volume (L) Dimensions (mm)
D D1 L L1 L2 B
CHW1000 1000 1000 1100 1696 730 1050 150
CHW2000 2000 1200 1300 2267 1050 1500 150
CHW3000 3000 1300 1400 2746 1300 1950 150
CHW4000 4000 1500 1600 2796 1300 1900 200
CHW5000 5000 1600 1700 3002 1400 2050 200
CHW6000 6000 1700 1800 3202 1450 2200 200
CHW8000 8000 1900 2000 3444 1650 2350 250
CHW10000 10000 1900 2000 4144 2050 3000 250
CHW15000 15000 2100 2200 4910 2500 3800 300
CHW20000 20000 2300 2400 5492 2800 4200 300
